格來圈/斯特封2

發(fā)布日期：2012-06-01 12:43:36　作者：眾高密封科技

格來圈/斯特封2

軸用斯特封尺寸表 Size Table of Axis Step Seal

Pull
Rod Diameter 拉桿直徑
Dh9
Groove outer Diameter
溝槽外徑
Bh9

Groove Width    溝槽寬度
F+0.2
Item NO.
型號
Pull Rod Diameter
拉桿直徑
Df8
Groove outer Diameter
溝槽外徑
Bh9
Groove Width
溝槽寬度
F+0.2
Item NO.
型號
4
8.9
2.2
ZGJ013-0040
38
53.1
6.3
ZGJ013-0380
5
9.9
2.2
ZGJ013-0050
38
48.7
4.2
ZGJ015-0380
6
10.9
2.2
ZGJ013-0060
40
55.1
6.3
ZGJ013-0400
7
11.9
2.2
ZGJ013-0070
40
50.7
4.2
ZGJ015-0400
8
15.3
3.2
ZGJ013-0080
42
52.7
4.2
ZGJ015-0420
8
12.9
2.2
ZGJ015-0080
42
57.1
6.3
ZGJ013-0420
10
17.3
3.2
ZGJ013-0100
45
60.1
6.3
ZGJ013-0450
10
14.9
2.2
ZGJ015-0100
45
55.7
4.2
ZGJ015-0450
12
19.3
3.2
ZGJ013-0120
50
65.1
6.3
ZGJ013-0500
12
16.9
2.2
ZGJ015-0120
50
60.7
4.2
ZGJ015-0500
14
21.3
3.2
ZGJ013-0140
56
71.1
6.3
ZGJ013-0560
14
18.9
2.2
ZGJ015-0140
56
66.7
4.2
ZGJ015-0560
15
19.9
2.2
ZGJ013-0150
60
75.1
6.3
ZGJ013-0600
15
22.3
3.2
ZGJ015-0150
60
70.7
4.2
ZGJ015-0600
16
23.3
3.2
ZGJ013-0160
63
78.1
6.3
ZGJ013-0630
16
20.9
2.2
ZGJ015-0160
65
80.1
6.3
ZGJ013-0650
18
25.3
3.2
ZGJ013-0180
70
85.1
6.3
ZGJ013-0700
18
22.9
2.2
ZGJ015-0180
75
90.1
6.3
ZGJ013-0750
20
30.7
4.2
ZGJ013-0200
80
95.1
6.3
ZGJ013-0800
20
27.3
3.2
ZGJ015-0200
85
100.1
6.3
ZGJ013-0850
22
32.7
4.2
ZGJ013-0220
90
105.1
6.3
ZGJ013-0900
22
29.3
3.2
ZGJ015-0220
95
110.1
6.3
ZGJ013-0950
25
35.7
4.2
ZGJ013-0250
100
115.1
6.3
ZGJ013-1000
25
32.3
3.2
ZGJ015-0250
105
120.1
6.3
ZGJ013-1050
28
35.3
3.2
ZGJ015-0280
110
125.1
6.3
ZGJ013-1100
28
38.7
4.2
ZGJ013-0280
115
130.1
6.3
ZGJ013-1150
30
40.7
4.2
ZGJ013-0300
120
135.1
6.3
ZGJ013-1200
30
37.3
3.2
ZGJ015-0300
125
140.1
6.3
ZGJ013-1250
32
42.7
4.2
ZGJ013-0320
130
145.1
6.3
ZGJ013-1300
32
39.3
3.2
ZGJ015-0320
135
150.1
6.3
ZGJ013-1350
35
42.3
3.2
ZGJ015-0350
140
155.1
6.3
ZGJ013-1400
35
45.7
4.2
ZGJ013-0350
150
165.1
6.3
ZGJ013-1500
36
46.7
4.2
ZGJ013-0360
160
175.1
6.3
ZGJ013-1600
36
43.3
3.2
ZGJ015-0360
170
185.1
6.3
ZGJ013-1700

 軸用斯特封尺寸表 Size Table of Axis Step Seal


Pull Rod Diameter 拉桿直徑
Dh9
Groove outer Diameter
溝槽外徑
Bh9
Groove
Width
溝槽寬度
F+0.2
Item NO.
型號
Pull Rod Diameter 拉桿直徑
Df8
Groove outer Diameter
溝槽外徑Bh9
Groove Width
溝槽寬度
F+0.2
Item NO.
型號
180
195.1
6.3
ZGJ013-1800
520
544.0
8.1
ZGJ013-5200
190
205.1
6.3
ZGJ013-1900
530
554.0
8.1
ZGJ013-5300
200
220.5
8.1
ZGJ013-2000
540
564.0
8.1
ZGJ013-5400
210
230.5
8.1
ZGJ013-2100
550
574.0
8.1
ZGJ013-5500
220
240.5
8.1
ZGJ013-2200
560
584.0
8.1
ZGJ013-5600
230
250.5
8.1
ZGJ013-2300
570
594.0
8.1
ZGJ013-5700
240
260.5
8.1
ZGJ013-2400
580
604.0
8.1
ZGJ013-5800
250
270.5
8.1
ZGJ013-2500
590
614.0
8.1
ZGJ013-5900
260
284.0
8.1
ZGJ013-2600
600
624.0
8.1
ZGJ013-6000
270
294.0
8.1
ZGJ013-2700
610
634.0
8.1
ZGJ013-6100
280
304.0
8.1
ZGJ013-2800
620
644.0
8.1
ZGJ013-6200
290
314.0
8.1
ZGJ013-2900
630
654.0
8.1
ZGJ013-6300
300
324.0
8.1
ZGJ013-3000
640
664.0
8.1
ZGJ013-6400
310
334.0
8.1
ZGJ013-3100
650
677.3
9.5
ZGJ013-6500
320
344.0
8.1
ZGJ013-3200
660
687.3
9.5
ZGJ013-6600
330
354.0
8.1
ZGJ013-3300
670
697.0
9.5
ZGJ013-6700
340
364.0
8.1
ZGJ013-3400
680
707.3
9.5
ZGJ013-6800
350
374.0
8.1
ZGJ013-3500
690
717.3
9.5
ZGJ013-6900
360
384.0
8.1
ZGJ013-3600
700
727.3
9.5
ZGJ013-7000
370
394.0
8.1
ZGJ013-3700
710
737.3
9.5
ZGJ013-7100
380
404.0
8.1
ZGJ013-3800
～1000



390
414.0
8.1
ZGJ013-3900




400
424.0
8.1
ZGJ013-4000




410
434.0
8.1
ZGJ013-4100




420
444.0
8.1
ZGJ013-4200




430
454.0
8.1
ZGJ013-4300




440
464.0
8.1
ZGJ013-4400




450
474.0
8.1
ZGJ013-4500




460
484.0
8.1
ZGJ013-4600




470
494.0
8.1
ZGJ013-4700




480
504.0
8.1
ZGJ013-4800




490
514.0
8.1
ZGJ013-4900




500
524.0
8.1
ZGJ013-5000




510
534.0
8.1
ZGJ013-5100
